It is a Toyota Raize 2020. The customer wants to add a new spare smart key to it. 4A HitagAES smart key.
4A HitagAES status “already locked”. The customer purchased a new key (the key looks exactly the same as the original, both internally and externally). The new one had the status “already locked”, the same picture with the ID47 Hitag3 keys on the Tank (and all cars of the same platform), which did not interfere with programming this key to the car.
Everything is clear with the key. Let’s move on.
We use through TechStream 18 and a techstream cable (vxdiag vcx nano Toyota or Mangoose JLR, no MINI VCI cheap cables). Choose the Toyota Raize 2019-2021 model and there is nothing there.
neither Body, nor Immo, nor enrty&start function.
Try to do it through Tank. Choose a Tank body M900 engine 1kr and year of manufacture 2016-2018.
Here we choose Body and then Utilities.
Go to Body, everything is fine, the module responds, then go to Utilities and select “add Key” from the list. If you select “add new key” nothing will work.
Well, that’s it, we operate according to the instructions. With the ignition on, turn off all additional devices, leave one door open – bring the attached key to the button, the car beeps – then bring the new key and ! click next!
Then the car will click the locks. You can all click Exit to complete the procedure or click Next to program the next key.
That’s it, the key is ready. Everyone is happy.
